Cable Connections

The diagrams on the following pages reference the following labels and notes.

Label

Manufacturer

Part Number

Description

Belden

8760,9207

Or

9463F

18 or 20 AWG twisted pair cable terminated with 3-pin XLR

Middle Atlantic (or equivalent)

CH-1

1 RU shielded chassis

Neutrik (or equivalent)

NC3FD-L-B-1

3 pole female chassis mount

Neutrik (or equivalent)

NC3MD-L-B-1

3 pole male chassis mount

Neutrik (or equivalent)

NA3MDF

3 PIN XLR M-F FEED THRU ADAPTER

Belden (or existing cabling)

1351A or 1533P

24 AWG, shielded cat 6 cabling

Belden

8760,9207 or 9463F

XLR3 M-F patch cord

Belden

8760,9207 or 9463F

18 or 20 AWG twisted pair cable



Label

Note

Wire according to table

Equipment rack, breakout box chassis and patch panel must be connected to safety earth

Connect up to 32 wall plate locations to patch panel with     individual CAT 5 cables

If multiple wall plates are co-located at a remote location,     daisy chain their wiring at the remote location and connect a     single CAT 5 cable from the remote location back to the     patch panel

Use short length, high quality XLR patch cords with shielded     connectors

Do not patch between separate power lines

Assemble item 6 to panel with male connectors to front
