Market Solution: House of Worship

Church with matrix, digital partyline and wireless


Hover your mouse over the diagram for a closer view.
PDF Download (449.06 KB)   Visio Download (449.06 KB)
JPG Download (1.09 MB)

Products

Clear-Com products shown in diagram are listed below. Click on the product model for more information.

BP210
Beltpack for DX210 System
BS210
Base Station for DX210 System
PRC-2
UHF Wireless IFB receiver beltpack
PTX-3
UHF wireless IFB Transmitter basestation with 256 selectable frequencies
IMF-3
3RU Interface module frame excluding PSU
TEL-14
Dual channel telephone hybrid module
FOR-22
Dual 4-wire/2-way TX Balanced module
i-Series Panels
V12LDXY
V-Series 12-Lever Key Panel
V12PDXY
V-Series 12-Pushbutton Key Panel
V24PDXY
V-Series 24-Pushbutton Key Panel
V24LDXY
V-Series 24-Lever Key Panel
V12RDX
V-Series 12-Rotary Key Panel
Eclipse HX-PiCo
36-port 1RU digital matrix frame with PiCo-Link feature for connecting two Eclipse HX-PiCo systems
BAL-8
1RU 8-port transformer isolation adapter
IFB-104
1RU 4-port IFB breakout Interface
CC-300
Single-ear standard headset
WP-2
2-Channel 3-Pin Selectable Intercom Outlet Wall Plate
HBP-2X
2-Channel HelixNet Beltpack
(Last Time Buy - Replaced with HXII-BP)
HMS-4X
4-Channel HelixNet Main Station

HS15
