Clear-Com to Present Voice Communications Solutions for Security and Defense at DSEI 2023

Scalable 1RU intercom system core supporting a wide range of intercom user stations and interfaces.​

The FSII-TVCR-IP-19 is an active transceiver antenna for the FSII-BP19 and FSIC-BP19 beltpacks. The transceiver connects to the Eclipse® HX matrix system via the E-IPA-HX interface card. Each transceiver can support up to 10 FSII-BP19 or FSIC-BP19 beltpacks. When supported with the E-IPA card, up to 50 1.9 GHz beltpacks (in North America or 64 beltpacks in EU countries) and up to 64 transceivers can be supported on one Eclipse HX matrix system.

The FSII-BASE-II is a base station for the wireless FreeSpeak II 1.9 GHz and 2.4 GHz active transceiver antennas and beltpacks. The FSII-BASE-II has four 2-wire connections for analog partyline connection, four 4-wire audio connections and four displays with soft keys. Dedicated stage announce (SA) output and program audio input are provided.

The FSII-TCVR-19 is an active transceiver antenna for the FSII-BP19 or FSIC-BP19 beltpacks. The antenna can be locally powered or powered via the FSII base station or matrix on shorter connections (less than 1000 ft). The FSII-TCVR-19 has a mount for wall or microphone stand. A green status light is visible from either mounting orientations. When mixed with FSII-TCVR-24 antennas, a single radio space can support up to 65-90 FreeSpeak Icon and FreeSpeak II 1.9 GHz or 2.4 GHz beltpacks.

The FSII-TCVR-24 is an active transceiver antenna for the FSII-BP24 beltpacks. The antenna can be locally powered or powered via the FSII base station or matrix on shorter connections (less than 1000 ft). The FSII-TCVR-24 has a mount for wall or microphone stand. A blue status light is visible from either mounting orientations. When mixed with FSII-TCVR-19 antennas, a single radio space can support up to 65-90 FreeSpeak II 1.9 GHz or 2.4 GHz beltpacks.
