System Diagram

Up to 64 user stations are controlled by a HelixNet Main Station (with HCS v2.1.0 software) using a browser-based Configuration Editor. The Main Station connects to the Industrial KB Stations over LAN and each Industrial KB Station is powered remotely using PoE (Power-over-Ethernet).
